01-005-CL Push-to-open hinge, clip-on

Cup diameter: 35mm
Opening angle: 110°
Cap depth: 11.3mm
Openning type: pushing
Installation: clip-on
Door thickness: 14-23mm
Overlay adjustment: ±2.5mm
Depth adjustment: ±2.5mm
Height adjustment: ±2.0mm

SKU: 01-005-CL Categories: ,
Variations

01-005-CL-48A

c22197

01-005-CL-48A2

full overlay/48/H2
