01-008-CL Concealed hinge, clip-on

Cup diameter: 35mm
Opening angle: 110°
Cap depth: 11.3mm
Openning type: two ways
Installation: clip-on
Door thickness: 14-22mm
Overlay adjustment: ±2.5mm
Depth adjustment: ±2.5mm
Height adjustment: ±2.0mm

SKU: 01-008-CL Categories: ,
Variations

01-008-CL-48A0

full overlay/48/H0

01-008-CL-48A0-x

full overlay/48/H0

01-008-CL-48A2

full overlay/48/H2
Crank: full overlay
Holes: 48
Plate height: H=2
Plate type: for chipboard screws

01-008-CL-48A2-body

full overlay/48/H2, hinge body

01-008-CL-48B0

half overlay/48/H0

01-008-CL-48B0-x

half overlay/48/H0

01-008-CL-48B2

half overlay/48/H2
Crank: half overlay
Holes: 48
Plate height: H=2
Plate type: for chipboard screws

01-008-CL-48C0

insert/48/H0

01-008-CL-48C0-x

insert/48/H0

01-008-CL-48C2

insert/48/H2
Crank: inset
Holes: 48
Plate height: H=2
Plate type: for chipboard screws
