10-117 Eccentric dowel, self-tapping

Mostly sold with: 10-218-115 and 10-201-115.

– Euroscrew thread for hole 5mm.
– Deep thread provides better fixaton.
– Dowel length 24 or 34mm.
– Dowel can be mounted with cross screwdriver PH2 or PZ2.
– Chamfer on thread tip (on some types) for more comfortable installation.

Variations

10-117-24

L=35mm, A=24,B=11

10-117-34

L=45mm, A=34,B=11
Cam distance: 34
Diameter: 5.0
Neck: 3.2
Thread: 6.3x11
Weight: 5.23-5.25 gr
