09-100 Roller system (symmetric)

Material:
upper roller – PVC
lower roller:
A: standard bearing + POM plastic
B: budget friendly bearing + PP plastic

According to customer’s request , mounting screws can be made with the same hexagon size , 4mm or 5mm. If there are no requirements, the standard hexagon sizes are the following:
down screw М5 – 4mm
upper screw D=5mm – 4mm
upper screw D=6mm – 5mm

Variations

09-100-608B06H375

608B/1.0/1.4/6/37.5,hardened
Down roller: thickness: 1.0
Screw type: hardened
Screw: 6
Upper roller: width: 37.5 ±0,2

09-100-608B06375

608B/1.0/1.4/6/37.5
Down roller: thickness: 1.0
Screw type: standard
Screw: 6
Upper roller: width: 37.5 ±0,2

09-100-608B06385

608B/1.0/1.4/6/38.5
Down roller: thickness: 1.0
Screw type: standard
Screw: 6
Upper roller: width: 38.5 ±0,2

09-100-629B06375

629B/1.0/1.4/6/37.5
Down roller: thickness: 1.0
Screw type: standard
Screw: 6
Upper roller: width: 37.5 ±0,2

09-100-629A26375

629A/1.2/1.4/6/37.5
Down roller: thickness: 1.2
Screw type: standard
Screw: 6
Upper roller: width: 37.5 ±0,2

09-100-629A06385

629A/1.0/1.4/6/38.5
Down roller: thickness: 1.0
Screw type: standard
Screw: 6
Upper roller: width: 38.5 ±0,2

09-100-629A06375

629A/1.0/1.4/6/37.5
Down roller: thickness: 1.0
Screw type: standard
Screw: 6
Upper roller: width: 37.5 ±0,2

09-100-629A05385

6000/1.0/1.4/5/38.5
Down roller: thickness: 1.0
Screw type: standard
Screw: 5
Upper roller: width: 38.5 ±0,2

09-100-629A05375

6000/1.0/1.4/5/37.5
Down roller: thickness: 1.0
Screw type: standard
Screw: 5
Upper roller: width: 37.5 ±0,2

09-100-608G26H385

608A/1.2/1.4/6/38.5,hardened
Down roller: thickness: 1.2
Screw type: hardened
Screw: 6
Upper roller: width: 38.5 ±0,2

09-100-608G25H385

608A/1.2/1.4/5/38.5, hardened
Down roller: thickness: 1.2
Screw type: hardened
Screw: 5
Upper roller: width: 38.5 ±0,2

09-100-608G25385

608A/1.2/1.4/5/38.5
Down roller: thickness: 1.2
Screw type: standard
Screw: 5
Upper roller: width: 38.5 ±0,2

09-100-608G05H385

608A/1.0/1.4/5/38.5,hardened
Down roller: thickness: 1.0
Screw type: hardened
Screw: 5
Upper roller: width: 38.5 ±0,2

09-100-600006375

6000/1.0/1.4/6/37.5
Down roller: thickness: 1.0
Screw type: standard
Screw: 6
Upper roller: width: 37.5 ±0,2

09-100-600006385

6000/1.0/1.4/6/38.5
Down roller: thickness: 1.0
Screw type: standard
Screw: 6
Upper roller: width: 38.5 ±0,2

09-100-608B05385

608B/1.0/1.4/5/38.5
Down roller: thickness: 1.0
Screw type: standard
Screw: 5
Upper roller: width: 38.5 ±0,2

09-100-608B05375

608B/1.0/1.4/5/37.5
Down roller: thickness: 1.0
Screw type: standard
Screw: 5
Upper roller: width: 37.5 ±0,2

09-100-608A26375

608A/1.2/1.4/6/37.5
Down roller: thickness: 1.2
Screw type: standard
Screw: 6
Upper roller: width: 37.5 ±0,2

09-100-608A06385

608A/1.0/1.4/6/38.5
Down roller: thickness: 1.0
Screw type: standard
Screw: 6
Upper roller: width: 38.5 ±0,2

09-100-608A06375

608A/1.0/1.4/6/37.5
Down roller: thickness: 1.0
Screw type: standard
Screw: 6
Upper roller: width: 37.5 ±0,2

09-100-608A0539

608A/1.0/1.4/5/39

09-100-608A05385

608A/1.0/1.4/5/38.5
Down roller: thickness: 1.0
Screw type: standard
Screw: 5
Upper roller: width: 38.5 ±0,2

09-100-608A05375

608A/1.0/1.4/5/37.5
Down roller: thickness: 1.0
Screw type: standard
Screw: 5
Upper roller: width: 37.5 ±0,2

09-100-600B06375

6000B/1.0/1.4/6/37.5
Down roller: thickness: 1.0
Screw type: standard
Screw: 6
Upper roller: width: 37.5 ±0,2

09-100-600B05385

6000B/1.0/1.4/5/38.5
Down roller: thickness: 1.0
Screw type: standard
Screw: 5
Upper roller: width: 38.5 ±0,2

09-100-600B05375

6000B/1.0/1.4/5/37.5
Down roller: thickness: 1.0
Screw type: standard
Screw: 5
Upper roller: width: 37.5 ±0,2

09-100-629B06385

629B/1.0/1.4/6/38.5
Down roller: thickness: 1.0
Screw type: standard
Screw: 6
Upper roller: width: 38.5 ±0,2
