01-091 Soft-closing hinge

Cup diameter: 35mm
Opening angle: 95°
Cap depth: 12mm
Closing type: soft closing (two ways)
Installation: clip-on, adjustment in 3 dimensions
Door thickness: 16-25mm
Overlay adjustment: ±2.5mm
Depth adjustment: ±2.5mm
Height adjustment: ±2.0mm
