01-500 Short hinge, slide-on, d35

Cup diameter: 35mm
Opening angle: 105°
Cap depth: 11.3mm
Openning type: two ways
Installation: slide-on
Door thickness: 14-25mm
Overlay adjustment: ±2.5mm
Depth adjustment: ±2.5mm
Height adjustment: ±2.0mm

SKU: 01-500 Categories: ,
Variations

01-500-48B-n

half/48//with nail
Crank: half overlay
Holes: 48
Plate type: with nail

01-500-48B-w

half/48/without nail
Crank: half overlay
Holes: 48
Plate type: without nail
