10-068-0610D13H4M6x10mm, D13, hex4 | - | - | - | - | |
10-068-0812D17H5M8x12mm, D17, hex5
Diameter of head: 17
Hex: 5
Length (L): 12
Thread: M8
| 17 | 5 | 12 | M8
| |
10-068-0822D16H5M8x22mm, D16, hex5
Diameter of head: 17
Hex: 5
Length (L): 22
Thread: M8
| 17 | 5 | 22 | M8
| |
10-068-0820D16H5M8x20mm, D16, hex5
Diameter of head: 19
Hex: 5
Length (L): 20
Thread: M8
| 19 | 5 | 20 | M8
| |
10-068-0818D17H5M8x18mm, D17, hex5
Diameter of head: 17
Hex: 5
Length (L): 18
Thread: M8
| 17 | 5 | 18 | M8
| |
10-068-0818D16H5M8x18mm, D16, hex5
Diameter of head: 16
Hex: 5
Length (L): 18
Thread: M8
| 16 | 5 | 18 | M8
| |
10-068-0817D16H5M8x17mm, D16, hex5
Diameter of head: 16
Hex: 5
Length (L): 17
Thread: M8
| 16 | 5 | 17 | M8
| |
10-068-0816D20H5M8x16mm, D20, hex5 | - | - | - | - | |
10-068-0816D19H5M8x16mm, D19, hex5 | - | - | - | - | |
10-068-0816D19H4M8x16mm, D19, hex4
Diameter of head: 19
Hex: 4
Length (L): 16
Thread: M8
| 19 | 4 | 16 | M8
| |
10-068-0816D17H5M8x16mm, D17, hex5 | - | - | - | - | |
10-068-0815D17H5M8x15mm, D17, hex5
Diameter of head: 17
Hex: 5
Length (L): 15
Thread: M8
| 17 | 5 | 15 | M8
| |
10-068-0815D16H5M8x15mm, D16, hex5
Diameter of head: 17
Hex: 5
Length (L): 15
Thread: M8
| 17 | 5 | 15 | M8
| |
10-068-08135D175M8x13.5mm, D17, hex5 | - | - | - | - | |
10-068-0812D16H5M8x12mm, D16, hex5
Diameter of head: 16
Hex: 5
Length (L): 12
Thread: M8
| 16 | 5 | 12 | M8
| |
10-068-0612D13H4M6x12mm, D13, hex4
Diameter of head: 13
Hex: 4
Length (L): 12
Thread: M6
| 13 | 4 | 12 | M6
| |
10-068-0811D16H5M8x11mm, D16, hex5
Diameter of head: 16
Hex: 5
Length (L): 11
Thread: M8
| 16 | 5 | 11 | M8
| |
10-068-0615D16H5M6x15mm, D16, hex5 | - | - | - | - | |
10-068-0615D15H4M6x15mm, D15, hex4 | - | - | - | - | |
10-068-0615D13H5M6x15mm, D13, hex5
Diameter of head: 13
Hex: 5
Length (L): 15
Thread: M6
| 13 | 5 | 15 | M6
| |
10-068-0615D13H4M6x15mm, D13, hex4
Diameter of head: 13
Hex: 4
Length (L): 15
Thread: M6
| 13 | 4 | 15 | M6
| |
10-068-0612D16H5M6x12mm, D16, hex5
Diameter of head: 15.5
Hex: 5
Length (L): 12
Thread: M6
| 15.5 | 5 | 12 | M6
| |
10-068-0612D16H4M6x12mm, D16, hex4 | - | - | - | - | |
10-068-0612D15H5M6x12mm, D15, hex5 | - | - | - | - | |
10-068-0612D15H4-9M6x12mm, D15,, hex4 | - | - | - | - | |
10-068-0612D15H4-8M6x12mm, D15, hex4
Diameter of head: 15
Hex: 4
Length (L): 12
Thread: M6
| 15 | 4 | 12 | M6
| |
10-068-0612D15H4M6x12mm, D15, hex4
Diameter of head: 15
Hex: 4
Length (L): 12
Thread: M6
| 15 | 4 | 12 | M6
| |
10-068-0612D13H5M6x12mm, D13, hex5
Diameter of head: 13
Hex: 5
Length (L): 12
Thread: M6
| 13 | 5 | 12 | M6
| |
10-068-1020D20H6M10x20mm, D20, hex6
Diameter of head: 20
Hex: 6
Length (L): 20
Thread: M10
| 20 | 6 | 20 | M10
| |
