hangers for cabinets
The information in the catalogue and on the website is given for reference only.
Please, ask for a sample to check.

view style:
View: 12 24 ALL
  • Placeholder

    10-541 Adjustable cabinet hanger

    - For rail suspension.
    - Enforced hook that have U-section.
    - Load capacity also depends on plastic material (see table)
    - Adjustment possibilities: Height: ± 7 mm
    Depth: max. 20 mm
    - Lift-off height: 7,5 mm

  • Placeholder

    10-543 Adjustable cabinet hanger

    - For rail suspension.
    - Solid body cab bear more loading.
    - Load capacity also depends on plastic material (see table)
    - Adjustment possibilities: Height: ± 10mm
    Depth: max. 12 mm
    - Lift-off height: 6 mm

  • Placeholder

    10-500 Cabinet hidden suspension bracket

    - For use behind the rear wall, rail suspension.
    - Mounted by 3 pins into the side panel, also has extra holes for additional screw connections.
    - Suitable for back panel recess measuring at least 16 mm.
    - Adjustment screws are secured against unintentional removal.
    - Easily adjusted with screw and gear.
    - Adjustment possibilities : Height: ± 9mm
    Depth: max. 25 mm
    - Lift-off height: 7.5 mm

  • Placeholder

    10-501 Cabinet hidden suspension bracket

    - Double sided universal bracket.
    - For use behind the rear wall, rail suspension.
    - Mounted by 3 pins into the side panel, also has extra holes for additional screw connections.
    - Suitable for back panel recess measuring at least 16 mm.
    - Adjustment screws are secured against unintentional removal.
    - Easily adjusted with screw and gear.
    - Adjustment possibilities : Height: ± 9mm
    Depth: max. 25 mm
    - Lift-off height: 7.5 mm

  • Placeholder
  • Placeholder

    10-544 Adjustable cabinet hanger

    - For rail suspension.
    - Solid body cab bear more loading.
    - Load capacity also depends on plastic material (see table)
    - Adjustment possibilities: Height: ± 11 mm
    Depth: max. 28 mm
    - Lift-off height: 6,5 mm

  • Placeholder

    10-546 Adjustable cabinet hanger

    - For rail and hool suspension.
    - Solid body cab bear more loading.
    - Enforced hook that have U-section.
    - Load capacity also depends on plastic material (see table)
    - Adjustment possibilities: Height: ± 9 mm
    Depth: max. 15 mm
    - Lift-off height: 6,5 mm

  • Placeholder

    10-547 Adjustable cabinet hanger w/ dowel

    - For rail and hook suspension.
    - Solid body cab bear more loading.
    - Enforced hook that have U-section.
    - Mounted without screws, on built-in sockets.
    - Load capacity also depends on plastic material (see table)
    - Adjustment possibilities: Height: ± 9 mm
    Depth: max. 15 mm
    - Lift-off height: 6,5 mm

  • Placeholder

    10-548 Cabinet hanger with cover

    - For rail suspension.
    - Solid body cab bear more loading.
    - Decorative cover.
    - Enforced hook that have U-section.
    - Load capacity also depends on plastic material (see table)
    - Adjustment possibilities: Height: ± 8 mm
    Depth: max. 20 mm
    - Lift-off height: 8,5 mm

  • Placeholder

    10-549 Cabinet hanger with cover

    - For rail suspension.
    - Decorative cover.
    - Solid body made of zinc alloy, can bear more loading.
    - Adjustment possibilities: Height: ± 7.5 mm
    Depth: max. 20 mm
    - Lift-off height: 5 mm
