soft closing, angled
The information in the catalogue and on the website is given for reference only.
Please, ask for a sample to check.

view style:
View: 12 24 ALL
  • Placeholder

    01-042 Soft-closing hinge, 45°, clip-on

    SGS tested: passed 85.000 openning cycles
    Cup diameter: 35mm
    Opening angle: 95°
    Cap depth: 11.3mm
    Closing type: soft closing
    Installation: clip-on
    Door thickness: 14-22mm
    Overlay adjustment: ±2.5mm
    Depth adjustment: ±2.5mm
    Height adjustment: ±2.0mm

  • Placeholder

    01-043 Soft-closing hinge, 90°, clip-on

    Cup diameter: 35mm
    Opening angle: 95°
    Cap depth: 11.3mm
    Closing type: soft closing
    Installation: clip-on
    Door thickness: 14-22mm
    Overlay adjustment: ±2.5mm
    Depth adjustment: ±2.5mm
    Height adjustment: ±2.0mm

  • Placeholder

    01-045 Soft-closing hinge, 165°, clip-on

    Cup diameter: 35mm
    Opening angle: 165°
    Cap depth: 11.5mm
    Closing type: soft closing
    Installation: clip-on
    Door thickness: 14-21mm
    Overlay adjustment: ±2.5mm
    Depth adjustment: ±2.5mm
    Height adjustment: ±2.0mm

  • Placeholder

    01-052 Soft-closing hinge, 45°, 3D

    Cup diameter: 35mm

    Opening angle: 95°

    Cap depth: 11.3mm

    Closing type: soft closing

    Installation: clip-on, adjustment in 3 dimensions
    Door thickness: 14-22mm

    Overlay adjustment: ±2.5mm

    Depth adjustment: ±2.5mm

    Height adjustment: ±2.0mm

  • Placeholder

    01-053 Soft-closing hinge, 90°, 3D

    Cup diameter: 35mm

    Opening angle: 95°

    Cap depth: 11.3mm

    Closing type: soft closing

    Installation: clip-on, adjustment in 3 dimensions
    Door thickness: 14-22mm

    Overlay adjustment: ±2.5mm

    Depth adjustment: ±2.5mm

    Height adjustment: ±2.0mm

  • Placeholder

    01-041 Soft-closing hinge, 30°, clip-on

    Cup diameter: 35mm
    Opening angle: 95°
    Cap depth: 11.3mm
    Closing type: soft closing
    Installation: clip-on
    Door thickness: 14-22mm
    Overlay adjustment: ±2.5mm
    Depth adjustment: ±2.5mm
    Height adjustment: ±2.0mm

  • Placeholder

    01-046 Soft-closing hinge, 155°, 2D

    Cup diameter: 35mm
    Opening angle: 155°
    Cap depth: 11.3mm
    Closing type: soft closing, adjustment in 2 dimensions
    Installation: clip-on
    Door thickness: 14-25mm
    Overlay adjustment: ±2.5mm
    Depth adjustment: ±2.5mm
    Height adjustment: ±2.0mm

  • Placeholder

    01-051 Soft-closing hinge, 30°, 3D

    Cup diameter: 35mm

    Opening angle: 95°

    Cap depth: 11.3mm

    Closing type: soft closing

    Installation: clip-on, adjustment in 3 dimensions
    Door thickness: 14-22mm

    Overlay adjustment: ±2.5mm

    Depth adjustment: ±2.5mm

    Height adjustment: ±2.0mm
